Excitation
5 to 10 VDC recommended, 12 VDC or VAC max.
Output
2 to 4 mV/V, nominal, depending on model
Accuracy
Standard configurations meet ASTM E83 class B-1 and ISO 9513 class 0,5 requirements for accuracy. A test certificate is included. Rod lengths >250 mm (10″) can affect the final class rating.
Linearity
≤0.15% of full scale measuring range, depending on model
Temperature Range
Ambient to 1200 °C max (2200 °F), all versions
Cable
Integral, ultra-flexible cable, 2.5 m (8 ft) standard
Contact Force
Adjustable, approximately 200 g depending on configuration
Operating Force
10 to 20 g typical
