Excitation
5 to 10 VDC recommended, 12 VDC or VAC max.
Linearity
≤0.15% of full scale measuring range
Temperature Range
Standard (-ST) is -40 °C to +100 °C (-40 °F to 210 °F)
Cable
Integral, ultra-flexible cable, 2.5 m (8 ft) standard
Specimen Size
Rebar diameter 8 – 36 mm (#3 – #11) standard, 6 – 60 mm (#2 – #18J) optional; coupler diameter up to 102 mm (4.0 inches)
Gauge Length
95 – 675 mm (3.74 – 26.6 inches) standard, up to 975 mm (38.4 inches) optional
