Gauge Length
4030: May be in the range 10 – 25 mm (specify when ordering)
Measuring Range
May be in the range 2.5 – 5.0 mm (specify when ordering)
Accuracy
<±100µm as supplied from Epsilon <±5µm with 3rd order polynomial linearization performed in the customer’s electronics
Temperature Range
-40 °C to +100 °C (-40 °F to 210 °F)
Cable
0.45 m (1.5 ft), multi-stranded, shielded, SS reinforced, Teflon® insulated
Standard Quick Attach Kit
Fits round samples up to 12 mm (0.5 inch) diameter and flats to 12 mm thick by 12 mm wide (0.5 inch by 0.5 inch)
Environment
Submersible in water and other liquids compatible with materials of construction
Power
Includes power supply for your country (specify)
