Field of View
52-500 mm. See specific optics packages; contact Epsilon for other options.
Working Distance
150-300 mm typical. See specific optics packages; contact Epsilon for other options.
Real-Time Data Rate
300-3000 Hz, >2000 Hz typical. Includes image frame rate, analysis, analog output, and digital output
Analog Output
±10VDC typical, short-protected. Selectable units & range. Includes 2.4 m (8 ft) shielded output cable with connector for test equipment.
Digital Output
16-64 bit at >2000 Hz typical, over RS232. Includes 1.8 m (6 ft) shielded null modem cable.
Resolution
<0.5 µm quasistatic, <2.5 µm dynamic, <0.1 µm creep; Typical RMS resolution at typical settings. Resolution is a function of the optics and filter settings.
Gauge Length
2 mm minimum, ≥4x specimen width or diameter recommended. For gauge lengths <10 mm contact Epsilon.
Power Supply
100-240 VAC, 50-60 Hz, 100W, IEC 320 C14 receptacle. Specify plug type when ordering
System Environment
10-40°C (50-100°F), for use and storage; 20-80% relative humidity non-condensing environments
